LED Driver For 48V Lights Work With 48V Track Light System GF-F360-V2

Short Description:

The non-dimming DC 48V LED driver is a power supply device designed for LED lighting systems operating on 48V direct current (DC) voltage.

This type of LED driver can be used when the lighting system does not require or support dimming. It is a simple power supply that provides a constant voltage output of 48V to the connected LEDs.

Dimming Non-Dimming
DC Output DC Voltage: 8-40V DC
DC Current: 150/250/300/350/400/450/
500/550/600/650/700/800mA (Customizable)
Line Regulation: ±2%
Load Regulation: ±2%
DC Input DC Input Voltage Range: 48VDC ±3%
DC Rated Voltage: 48VDC
Efficiency: >90%
Protection Short-circuit: Hiccup mode
No-load protection
Negative reverse connect protection
Environment Working Temp.: -20 ~ +45C°
Working Humidity: 20 ~ 90% RH, non-condensing
Storage Temp.: -20 ~ +70C°
Storage Humidity: 10% ~ 90% RH


Product Detail

Product Tags

GF-F360-V2
48V-driver

Specifications

Name DC48V Non-Dimming LED Driver
Supplier LEDEAST
Picture   Size: 50*14*6mm
Model GF-F360-V2
Dimming Non-Dimming
DC Output DC Voltage: 8-40V DC
DC Current: 150/250/300/350/400/450/
500/550/600/650/700/800mA (Customizable)
Line Regulation: ±2%
Load Regulation: ±2%
DC Input DC Input Voltage Range: 48VDC ±3%
DC Rated Voltage: 48VDC
Efficiency: >90%
Protection Short-circuit: Hiccup mode
No-load protection
Negative reverse connect protection
Environment Working Temp.: -20 ~ +45C°
Working Humidity: 20 ~ 90% RH, non-condensing
Storage Temp.: -20 ~ +70C°
Storage Humidity: 10% ~ 90% RH
Others IP Rate: IP22
MTBF: 50000 hours
Warranty 3 Years
