Bluetooth Mesh Control LED Driver Customizable DIP-Switch LEDEAST TUYA-BLE-BT8C

Short Description:

The Bluetooth mesh control LED driver is a LED driver that utilizes Bluetooth mesh technology to control and manage LED lighting fixtures
With the Bluetooth mesh control LED driver, users can conveniently control the brightness, color and other settings of the LED lights through a dedicated mobile app or other control devices.

Input Voltage: 48VDC ±3%
Output Voltage: 3-42VDC
Output Current: See content on right
Dimming Type: TUYA Control (Dimming / CCT Adjustable)
Efficiency: >90%
Power Factor: 1 Working
ENV.: -20 ~ +45°C / 20% ~ 90% RH
Storage ENV.: -20 ~ +70C° / 10% ~ 90%
RH MTBF: 50000 hours Control Mode: APP (Group / Single)/Remote/Voice (Alexa/Google Home)/86 Panel,APP: Tuya/Smart life


Product Detail

Product Tags

TUYA-BLE-BT8C
48V-driver

Specifications

Name DC48V Bluetooth Dimming LED Driver
Supplier LEDEAST

Size: 54*13.5*11mm

Model BT8C
DC Output Current Customizable (Non-DIP-Switch): 150-700mA

Depends on your requirement

Dimming Bluetooth Dimming
DC Output DC Voltage: 3-42V DC
Line Regulation: ±2%
Load Regulation: ±2%
DC Input DC Input Voltage Range: 48VDC ±3%
DC Rated Voltage: 48VDC
Efficiency: >90%
Protection Short-circuit: Hiccup mode
No-load protection
Negative reverse connect protection
Environment Working Temp.: -20 ~ +45C°
Working Humidity: 20 ~ 90% RH, non-condensing
Storage Temp.: -20 ~ +70C°
Storage Humidity: 10% ~ 90% RH
Others IP Rate: IP22
MTBF: 50000 hours
Warranty 5 Years

OEM led driver (2)0
